ATLAS NG: The ATSC 3.0 and DVB universal broadcast analyzer

ATLAS NG is a multipurpose NextGen TV ATSC 3.0 and DVB analyzer which includes 5G and covers the most stringent requirements for broadcast professionals, with ST 2110 protocol support (optional). DVB-S2x, IPTV, Fiber optics, 3G-SDI, Transport stream ASI, Wi-Fi… all checked!

Datasheet

Video

Manual

REQUEST A QUOTE

Do you need more help?

ATLAS NG is a broadcast spectrum analyzer capable of taking measurements up to 6 GHz covering the S and C bands, where an increasing number of technologies are all fiercely competing for bandwidth. It includes the latest broadcast technologies such as ATSC 3.0 and DVB-S2x in addition to 5G interference detection

It includes a 3G-SDI input to run a full 3G-SDI signal diagnosis, including a professional audio meter and eye diagram, and features an external SDI input for that task, other than the standard ASI input and output.

With optional ST 2110 protocol support and communication with network elements such as the master clock, the ATLAS NG helps ensure the correct operation of live broadcast links and studio productions.

Includes an IPTV analyzer. The omnipresence of IP technology in the broadcast industry makes it compulsory for an analyzer to be capable of feeding from IPTV signals and monitor them. Therefore, it becomes essential to have at hand a tester that can monitor and picture IPTV streams.

The new multitouch user interface based on customizable docking pannels ensures an improved user experience. The analyzer is easier to use than ever before!

BROADCAST STANDARDS
Digital terrestrial TV / Radio	DVB-T, DVB-T2 (T2-base, T2-lite), ISDB-T/Tb (full seg / 1seg), ATSC 1.0, ATSC 3.0, DAB, DAB+
Digital cable	DVB-C, DVB-C2, J.83 annex-B, 16/64/256-QAM
Digital satellite	DVB-S, DVB-S2 VCM/ACM/CCM, DVB-S2x, DSS, QPSK
Analogue	Analogue terrestrial (PAL, SECAM, NTSC), FM RDS

SPECTRUM ANALYZER MODE	From 5 MHz to 6 GHz

IPTV MULTICAST/UNICAST OPERATING MODE	More than 20 measurements (including Jitter, Packet rate, Histogram + jitter, Inter Packet Arrival Time). Multicast. T2MI&BTS reception.

SD/HD/3G-SDI OPERATING MODE	3 Gbps input/output. Eye statistical diagram, CRC error detection, 16 AES3 audio channel monitoring, 1080p 60 pattern chart.

WIFI 802.11 ac/a/b/g/n ANALYZER OPERATING MODE	Spectrum analyzer + WiFi dongle. RSSI, Access point occupancy, SNR, Noise

ASI-TS OPERATING MODE	ASI-TS TS, T2MI and BTS support

4G/5G (optional) TELEPHONY OPERATING MODE	Dual SIM. Uplink/Downlink bands indication over the spectrum. Measurements: RSSI, RSRP, RSRQ, SINR, SRXLEV.

INPUTS AND OUPUTS

Universal RF input (N-type, female 50 Ω)
ASI/SDI input and output (BNC female, 75 Ω 3 Gbps)
SFP+ connector
Analogue audio/video input (jack 3.5 mm)
HDMI™ output (v1.4b up to 3840x2160 pixels @30 Hz)
USB 2.0 master/device (Type C). Mass storage and remote control commands
Ethernet (RJ45) for webControl and remote control commands
Optical input (FC/APC, female)
1 PPS / 10 MHz reference input
IPTV input (RJ45 Ethernet, 10/100/1000 Mbps)
Stereo headphone audio output (jack 3.5 mm)
USB 3.0 host (A-type, USB-CDC devices)
CAM (DVB-CI compliant, module input
Double SIM card slot (optional)

FUNCTIONS

Constellation diagram
LTE ingress test
Dynamic echoes analysis
StealthID (instant identification of tuning parameters)
PLS (Physical Layer Scrambling)
Ultra fast Spectrum analyzer
4K decoder
MAX and MIN hold
FM RDS measurement and decoding
Screenshots and Datalogger for measurement reports
Beacon-Flyaways SNG and VSAT
Wideband LNB
WiFi
LTE 1.8 GHz
Service Recording
Field strength measurement
Task planner
Merogram
Spectrogram
Signal monitoring
Remote control (webControl)
MER by carrier
GPS (included) coverage analysis
Video/Audio Streaming
SCAN + TILT
TS recording
TS analysis
Shoulder attenuation
IPTV multicast measurement and decoding
Network delay
DVB-2 MI analysis
Eye diagram (HD-SDI, 3G-SDI)
ALP recording
Carrier Frequency Drift Test
Full band optical power measurement
8 GB internal memory, expandable via USB

OPTIONS	Optical fibre: Selective optical power meter + optical to RF converter Advanced measurements for FM radio Advanced measurements for DAB/DAB+ digital radio 4G/5G measurements Optical SDI and ASI output Optical SDI and ASI input ST2110 protocol support

Comparative table ATLAS and RANGER analyzers
More details on ATLAS NG
What is ATSC 3.0 and what are its innovations?
ATSC 3.0 technical overview
Key factors that make ATLAS NG broadcast analyzer a multidisciplinary equipment

Quick reference guide (English) (3,77 MB)
Quick reference guide (Spanish) (3,77 MB)
User manual (English) (17,71 MB)
Quick reference guide (French) (3,77 MB)
User manual (Spanish) (17,74 MB)
Firmware release 2.6.2 for ATLAS NG Update procedure: Requires ATLAS software version above 1.4.0. Reboot your equipment (important), then supply it by AC power to avoid running out of battery. Unzip the file to the root of a pendrive and insert it in the top USB port of the instrument. Perform the update by selecting Settings › Update. (479,53 MB)
