DTT receivers with two identical ASI-TS outputs.

REQUEST A QUOTE

Do you need more help?

The DT-312 modules are COFDM modulators compatible with DVB-T (DTT) standard. They can receive a DTT multiplex and extract the transport stream in TS-ASI format.

Each one of DT-312 receivers has two identical TS-ASI outputs

RF INPUT	2 DVB-T independent inputs
Connector	F-Type female, Impedance 75 Ω

TS OUTPUT	2 independent double DVB-ASI outputs
Connector	BNC female, Impedance 75 Ω

CONFIGURATION AND POWER SUPPLY	Through the DT-800 Control and Power module. Control can be made remotely from to PC
