PD-184: High precision TRMS tester

PD-184: High precision TRMS tester

Digital multimeters featuring Dc precission of 0.05%, and including Bluetooth connection to Android devices, datalogger, voice and temperature measurement.


High precision TRMS multimeters model PD-184 allow transferring via Bluetooth the live measurements, or transferring the measurements stored in the digital multimeter itself. Bluetooth connectivity also enables the remote control of the digital multimeter, as well as using voice speech synthesis to read the measurements as they are taken thus using the multimeter leaving the screen unattended.

The high precision in DC (0.05%) of PD-184 multimeters ensures reliable measurements in any professional field.

PD-184 digital multimeter has the most common measurements for DC and AC (Voltage, Current), Resistance, Capacity, Frequency, Max/Min Hold, Diode test…

They include temperature measurement up to 400 ºC (752 ºF) and storage capacity for up to 10000 measurement points.

VOLTAGE
  • DC: From 220 mV to 1000 V
  • AC: From 220 mV to 750 V
CURRENT
  • DC: From 220 μA to 20 A
  • AC: From 220 μA to 20 A
RESISTANCE From 220 Ω to 220 MΩ
CAPACITY From 22 nF to 220 mF
FREQUENCY From 22 Hz to 220 MHz
DUTY CYCLE From 0,1% to 99,9%
TEMPERATURE From -50 ºC to 400 ºC (-58 to 752 ºF)
True RMS Yes
OTHER FEATURES
  • Diode and Continuity test
  • Data hold
  • Max/Min hold
  • Datalogger
BLUETOOTH CONNECTIVITY
  • Bluetooth connection with mobile devices (requires Android 7.0 or higher)
  • Voice measurements
  • Measurements display
  • Graph analysis
  • Remote control
