If you are looking for a reason to update your test equipment, here it comes the new ATLAS NG. A multipurpose and feature packed spectrum analyzer which covers the most stringent broadcast requirements. ATSC 3.0, DVB-S2x, IPTV, Fiber optics, 3G-SDI, ALP and transport stream, ASI… all checked!
MORE INFORMATION ›
When broadcast signals pass through the amplifier on the transmitter side, unwanted RF components may appear on either side of the RF channel. Its shape resembles two shoulders and hence their name.
PLAY VIDEO ›
With this tool, a drive test analysis is carried out to map the coverage of a specific transmitter. We will be able to overlay the data on a Google Earth map.
PLAY VIDEO ›
With this option we can work with DAB or DAB+ digital radio signals, decode them and carry out detailed analysis of their carriers and even the NULL and PRS symbols that allow the receiver to synchronize to the signal.
PLAY VIDEO ›
They are typically used in DVB-S2 and DVB-S2x. They allow, for example, to modulate HD services in 32APSK while an SD version of those services is also modulated in a more robust modulation such as QPSK. All of them under the same DVB-S2 or DVB-S2x carrier.
PLAY VIDEO ›
The audio layer levels of any service in the transport stream can be displayed, either directly from the ASI input, from a demodulated RF signal, or from an IP multicast service.
PLAY VIDEO ›
You can connect an SDI signal to the meter and view all metadata related to the video and audio layers, measure the audio loudness of its up to 16 audio channels, and use the SDI eye analyzer to study and identify jitter, distortion, or noise artifacts.
PLAY VIDEO ›
The ATLAS NG can analyze T2/MI signals received either by RF from a DVB-S2 or DVB-S2x transponder, IP multicast stream or directly through the ASI input.
PLAY VIDEO ›
